What Info Do I Need To Provide

Site plan (PDF format) scale 1:100 (showing North point, adjacent buildings/structures)
Floor Plans (PDF format), include Floor coverings
Elevations (PDF format)
Sections (PDF format)
Construction Type specified eg: Wall types (brick veneer) and finishes
Electrical & Lighting Plan
Window Schedule, including sizes. Glazing performance types, Frame type (eg: Awning, double hung).
Type and location of exhaust fans, skylights.
Insulation levels with R rating amount

Whole of Home Checklist- Provide the below information.

Table 12-2: checklist – information to collect for Whole of Home rating

Category	Information for rating
Heating and cooling	Appliance type(s) Efficiency rating system (if applicable) Star rating (if applicable) Zone(s) the appliance(s) service
Cooling	Appliance type(s) Efficiency rating system (if applicable) Star rating (if applicable) Zone(s) the appliance(s) service
Hot water	Appliance type Capacity Make and model Efficiency rating system (if applicable) Peak/off peak
Pools and spas	Volume or surface area (to calculate volume) Pump type Star rating
Cooktop	Type Fuel source
Oven	Fuel source
PV	For each array: • orientation • slope • size (kW) Inverter size PV export limit (if value other than 5kW)
Battery	Type Capacity (kWh)
